AUXILIARY EQUIPMENTS

  • The technology and development engineers at oil-free technology INDO-AIR did extensive research on the critical components of the compressors to operate in oil free operating conditions.

      User Industries :

    •  Pneumatic Press

    • Road Building Machines

    • Ceramic

    • Pneumatic Tools

    • Ore Processing

    • Rubber Factories

    • Steel Fabrication

    TECHNICAL SPECIFICATIONS :

    MODEL CFM Working pressure
    Kg/cm 2    		 Conn. BSP Refrigerant Power Supply
    v/ph     		Condensor
    type     		Normal Power Consumption kw Length
    mm    		 Width
    mm    		 Height
    mm     		Weight
    kg
    IAD 015-16 15 16 ½" R 134a 220/1 Air 0.19 400 500 550 32
    IAD 025-16 25 16 ½" R 134a 220/1 Air 0.19 400 500 550 32
    IAD 045-16 45 16 ½" R 134a 220/1 Air 0.37 400 500 550 35
    IAD 060-16 60 16 ¾" R 134a 220/1 Air 0.37 550 550 730 60
    IAD 080-16 80 16 ¾" R 134a 220/1 Air 0.60 550 550 730 65
    IAD 100-16 100 16 1 ½" R 134a 220/1 Air 0.60 700 750 900 78
    IAD 150-16 150 16 1 ½" R 22 220/1 Air 1.40 700 750 900 90
    IAD 200-16 200 16 1 ½" R 22 220/1 Air 1.40 700 750 900 92
    IAD 250-16 250 16 1 ½" R 22 220/1 Air 1.70 700 750 900 155
    IAD 300-14 300 14 2" R134a/R 22 440/3 Air 1.70 900 770 1250 155
    IAD 400-14 400 14 2" R134a/R 22 440/3 Air 2.30 1000 800 1500 164
    IAD 500-14 500 14 3" R134a/R 22 440/3 Air 2.30 1500 1500 1750 250
    IAD 600-14 600 14 3" R134a/R 22 440/3 Air 3.10 1500 1500 1750 250
